Features
Highly precise cryosections
Engineered for uncompromising accuracy, the Dakewe VANGO CT620 cryostat microtome delivers ultra‑stable performance through an all‑new cooling system that cuts vibration by 67% compared with the CT520. This advancement enables true 1 μm precision—consistent, reliable, and ready for your most demanding cryosectioning workflows.
Multi-point cooling control
To guarantee every tissue type is sectioned at its optimal hardness, the Dakewe VANGO CT620 cryostat microtome applies multi‑point cooling control across the chamber, specimen head, quick‑freeze shelf, and blade holder. Temperatures remain precisely regulated, supporting reproducible morphology and dependable diagnostic outcomes.
Rapid freezing performance
Built for high‑throughput laboratories, the Dakewe VANGO CT620 cryostat microtome reaches working temperature in just 1.5 hours and offers large freezing capacity with 20 freezing stations, including 2 Peltier elements, minimizing downtime and maintaining steady output under heavy workloads.
Peace‑of‑mind management
An upgraded permissionn system enhances laboratory management by limiting feeding control and parameter adjustments to authorized users only—supporting a secure, accountable workflow.
Programmable defrosting, disinfection, and activation/sleep cycles further simplify routine maintenance and keep operation running smoothly.
Designed for sustainability
The all-new cooling system on the Dakewe VANGO CT620 cryostat microtome, together with a refrigerant that has negligible global-warming impact, achieves up to a 50% reduction in power consumption. This design also delivers a marked reduction in noise, shaping a greener, more comfortable laboratory environment.
Specifications
| Refrigerant | R290 (IPCC6, GWP: 0.02) |
|---|---|
| Dimensions (W x D x H) | 830 (including handwheel) x 910 (including rear grip) x 1300 mm |
| Weight | 183 kg |
| Power requirements | 220-240 VAC，50Hz/60 Hz，1000 VA； 100-120 VAC，50Hz/60 Hz，1000 VA; |
| Section thickness range | 0.5 - 100 μm |
| Trimming thickness range | 5 - 800 μm |
| Horizontal feed | 30 ± 1 mm |
| Vertical stroke | 62 ± 1 mm |
| Retraction | 0-100 μm in increments of 5.0 μm |
| Temperature range | At ambient temperature of 20 °C Freeze shelf: -10 °C to -42 °C ± 5°C Specimen head: -10 °C to -50 °C ± 5°C Blade holder: -15 °C to -30 °C ± 5°C Chamber: -15 °C to -30 °C ± 5°C |
| Freezing stations | 18 stations + 2 Peltier elements |
| Peltier elements | -60 °C + 3 °C (at freeze shelf temperature of -42 °C (+5 °C) |
| Blade holder | High and low profile |
